2009 Massey Ferguson 1635 4WD Platform/Cab


Request a Quote Financing Calculator Request a Brochure Financing Form

Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

Print Brochure

It's about work. It's about play. It's about time.


Our new generation of compact tractors offers everything you've been waiting for. And of course it's productive - That's pure Massey Ferguson. We turn practical necessity into guilty pleasure.


The first and only compact that's a perfect 10. When you're on one, there's only one way to describe the feeling - the sky's the limit.


Engine: Powered by efficient Iseki 3-or-4 cylinder liquid-cooled diesel engines, designed with clean-air technology to meet Tier IV interim emissions compliance.


Transmission: A powerful array of transmission options: Three-Range Hydrostatic (HST), 12x12 DynaQPSTM, 12x12 PowerShuttle, and 8x8 SynchroShuttle. All models are equipped with traction-boosting 4WD and differential lock to get you in and out of tight spots.


Hydraulics: Economical and easy to use, they earn their keep by providing increased pressure and oil flow that helps you lift more, work faster and get far more done in far less time.


3 Point Hitch: The 3-point hitch, patented by Harry Ferguson, allows you to use a wide range of implements and offers precise position and response control.


Independent PTO: Easy to operate with push-button control, it increases productivity, reliability and safety. With no clutching and no reaching for levers, you can operate rear and mid PTO independently or simultaneously.


Operator's Area: We’ve delivered on what what our customers really need: An even larger operator’s area, with an easy-entry, easy-exit, uncluttered environment. Plus,you’ll enjoy features like right-hand fender mounted controls to reduce fatigue, and the fact that all models have cab options.


Serviceability: With quick access to basic service points and a one-piece EZlift all-steel hood, the MF1600 Series compact tractors work hard at making maintenance easy.


Accessories: You can tailor the MF1600 Series tractor exactly to your liking by selecting everything from tires to canopies, work lights, wheel weights and grille guards.


Implements: With a full range of Massey Ferguson implements available, we are ready to help you take on almost any task.

    Engine
    • Gross engine: 35.7 hp (26.6 kW)
    • PTO HP: Gear: 27.1 hp (20.2 kW); HST: 25.8 hp (19.2 kW)
    • Rated engine speed: 2,600 RPM
    • Type: 3-cylinder diesel
    • Displacement: 100.5 cu. in. (1.6 l)
    • Cooling system: Liquid cooled
    • Fuel tank capacity: Platform: 9.2 gal. (35 l); Cab: 10.5 gal. (40 l)
    Transmission
    • PowerShuttle: 12Fx12R
    • Hydrostatic w/cruise: 3 range
    • Rear brakes: Wet disc
    PTO
    • Rear PTO type: Ind. 540 RPM
    • Control: Electro-hydraulic
    • Mid PTO type: 2,000 RPM (opt.)
    Hydraulics
    • Type of system: Open center
    • Flow at remotes: 11.6 gpm (43.9 lpm)
    • Pwr steering flow: SS: 4.9 gpm (18.5 lpm), HST/PS: 6 gpm (22.7 lpm)
    • Total flow: Platform: 16.5 gpm (62.3 lpm), Cab: 17.6 gpm (66.5 lpm)
    • Factory-installed joystick: Std
    • Rear auxiliary remotes: 3 spool opt.
    3-Point Hitch
    • ASAE hitch: Cat. I
    • Controls: Position
    • Rate of drop control: Standard
    • Lift capacity @ hitch point: 2,800 lbs. (1,270 kg)
    • Type of stabilizers: Telescopic bar
    • Type of link ends: Telescopic
    Operator Area
    • Platform type: Flat isolated
    • ROPS: Folding
    • Seat type: Suspended
    • Seat belt type: Retractable
    • Hood type: One-piece flip up
    Dimensions with ag tires
    • Overall length: 122 in. (3,100 mm)
    • Min. overall width: 64.5 in. (1640 mm)
    • Max. height over ROPS: Platform: 100 in. (2540 mm), Cab: 86.6 in. (2200 mm)
    • Ground clearance: 14.2 in. (360 mm)
    • Wheelbase: 69.7 in. (1,770 mm)
    • Shipping weight: Platform: 3175 lbs. (1440 kg); Cab: 3527 lbs. (1600 kg)
    Optional Implements
    • Loaders
    • Backhoes
    • Landscape Rakes
    • Box Blades
    • Grader Blades
    • Post Hole Digger
    • Mid-Mount Mowers
    • Rear-Mount Mowers
    • Turf Flex Finish Mower
    • Rotary Cutters
    • Rotary Flex Cutters
    • Rotary Tillers
    • Dozer Blade
    • Snow Blower
    • Rotary Broom

    Specifications

    Engine
    Engine Manufacturer Iseki
    Engine Type Type: 3-cylinder diesel ; Displacement: 100.5 cu. in. (1.6 l) ; Cooling system: Liquid cooled
    Horsepower 35.7 hp (26.6 kW)
    PTO HP Gear: 27.1 hp (20.2 kW); HST: 25.8 hp (19.2 kW)
    Rated RPM 2,600 RPM
    Specifications
    Wheelbase 69.7 in. (1,770 mm)
    Height Platform: 100 in. (2540 mm), Cab: 86.6 in. (2200 mm)
    Width 64.5 in. (1640 mm)
    Weight Platform: 3175 lbs. (1440 kg); Cab: 3527 lbs. (1600 kg)
    Ground Clearance 14.2 in. (360 mm)
    General
    Fuel Capacity Platform: 9.2 gal. (35 l); Cab: 10.5 gal. (40 l)
    Transmission PowerShuttle: 12Fx12R ; Hydrostatic w/cruise: 3 range
    Brakes Wet disc
    Hydraulics Open center

    Compare Models

    Print








    Year 2009
    Manufacturer Massey Ferguson
    Model 1635 4WD Platform/Cab
    Style Compact
    Engine
    Engine Manufacturer Iseki
    Engine Type Type: 3-cylinder diesel ; Displacement: 100.5 cu. in. (1.6 l) ; Cooling system: Liquid cooled
    Horsepower 35.7 hp (26.6 kW)
    PTO HP Gear: 27.1 hp (20.2 kW); HST: 25.8 hp (19.2 kW)
    Rated RPM 2,600 RPM
    Bore and Stroke
    General
    Fuel System
    Fuel Capacity Platform: 9.2 gal. (35 l); Cab: 10.5 gal. (40 l)
    Transmission PowerShuttle: 12Fx12R ; Hydrostatic w/cruise: 3 range
    Brakes Wet disc
    Hydraulics Open center
    Drive Type
    Specifications
    Wheelbase 69.7 in. (1,770 mm)
    Height Platform: 100 in. (2540 mm), Cab: 86.6 in. (2200 mm)
    Width 64.5 in. (1640 mm)
    Weight Platform: 3175 lbs. (1440 kg); Cab: 3527 lbs. (1600 kg)
    Ground Clearance 14.2 in. (360 mm)
    Tire Size
